(New Open Box) RATTMMOTOR CNC Spindle Motor Kit 220V 2.2KW Water Cooled Spindle Motor ER20 24000RPM

Brand: Rattmmotor
Voltage: 220V
Condition: New Open Box

About the Item: 【2.2KW Spindle Motor】: ①This is a 220V-2.2KW water-cooled 8A Φ 80x213mm spindle motor come with a ER20 nut and collet. Frequency is 400HZ, 0.003--0.005 accuracy and runout off is Less than 0.02mm. ②Speed of The Spindle Motor : 0-24000RPM. Because it is a high-speed spindle motor, the spindle speed must not be lower than 9000 rpm during the use of the spindle. It should be noted that the spindle only can rotate clockwise but not counterclockwise.
2.2KW VFD】①Parameters: Input Voltage: 220V(+/-15%), Output Voltage: 220VAC, Input Frequency: 50-60 Hz, Output Frequency: 0-1000 Hz, Input Phase: 1 phase, Output Phase: 3 phase, Current: 11A. It provide a variety of fault protection functions: over-current, over-voltage, under-voltage, over-heat, overload, lack of equal real-time monitoring and protection to ensure safe operation.
②Other Fuctions: With over torque and under torque detection; With jump frequency control function, it can effectively suppress mechanical resonance and make the system more stable and reliable.It can also avoid the impact of production due to instantaneous power failure because of instantaneous power-down retention function. What's more, it supports multiple frequency settings: digital setting, analog setting, PID setting, RS485 communication setting,etc.
